Industrial Stove Burner Motor

Industrial Stove Burner Motor Specification

Pressure
Atmospheric

Torque
0.26 Nm

Current Type
AC

Rated Voltage
220V

Horse Power
0.05 HP

Poles Number
2

Efficacy
Standard

Sealed Type
Totally Enclosed

Voltage
220V

Power Rating
40W

Standard
IS 996

Ambient Temperature
-10C ~ +45C

Bearing Type
Ball Bearing

Motor Type
Induction Motor

Cooling Method
Air Cooled

Starting Type
Capacitor Start

Rated Frequency
50 Hz

Features
Corrosion Resistant, Long Life, Energy Saving

Noise Level
<60 dB

Product Type
Motor

Output Power
40W

Frequency (MHz)
50 Hz

Protect Feature
Thermal Protection

Phase
Single Phase

Speed
1440 RPM

Power
40W

Color
Black

Dimension (L*W*H)
140 x 120 x 70 mm

Weight
2.8 Kg

Shaft Diameter
8 mm

Mounting Type
Foot Mounted

IP Rating
ip44

Voltage Tolerance
10%

Frequency Tolerance
5%

Compatible with
Various Industrial Gas Stove Models

Rotation
CW/CCW

Material
Cast Iron Body

Temperature Rise
< 60K

Application
Commercial Kitchen, Industrial Cooking Equipment

Duty
Continuous (S1)

Service Factor
1.0

Insulation Class
B

Shaft Length
38 mm

About Industrial Stove Burner Motor

The Siddhapura Brothers Stove Burner Motor is specially designed to play a critical role in eco stove burner systems by driving the screw conveyor mechanism.

This motor operates by rotating the screw conveyor, which in turn controls the movement of pellets (fuel) into the burner chamber. By ensuring a steady and controlled fuel supply, it helps maintain consistent combustion and efficient heat generation.

Engineered for precision and reliability, the motor delivers stable torque required to smoothly drive the conveyor without interruption. This controlled rotation prevents fuel overflow or uneven burning, resulting in improved fuel efficiency and reduced smoke emissions. I

t is ideal for use in biomass and pellet-based eco stove systems widely used in commercial and industrial applications.

The motor is built with a robust housing and high-quality components to withstand continuous operation in high-temperature environments.

Its compact design allows easy installation within stove assemblies, while low noise and minimal vibration ensure smooth performance.

With low maintenance requirements and energy efficient operation, the Siddhapura Brothers Stove Burner Motor offers a dependable and cost-effective solution.

It enhances the overall performance of eco stove systems by ensuring precise fuel feeding and consistent burner operation.

Reliable Performance for Heavy-Duty Kitchens

This industrial stove burner motor is designed to operate seamlessly under continuous load, making it ideal for commercial kitchens and large-scale industrial cooking facilities. It features a foot-mounted, totally enclosed structure for stability and dust prevention. The high-quality ball bearing minimizes noise (<60 dB) and ensures a smooth, consistent rotation. With a strong service factor and air-cooled efficiency, operators can count on the motor's enduring reliability in high-demand scenarios.

Built to Withstand Harsh Environments

Constructed with a corrosion-resistant cast iron body and compliant with IS 996 standards, the motor maintains optimal functionality even in challenging kitchen atmospheres. Thermal protection and insulation class B safeguard against overheating, while the sealed IP44 enclosure protects the internal components from splashes and dust. Designed for atmospheric pressure environments, it performs reliably at ambient temperatures ranging from -10C to +45C.

FAQ's of Industrial Stove Burner Motor:

Q: How can I install the Industrial Stove Burner Motor in my commercial kitchen setup?

A: The motor is designed with a foot-mounted base for easy and secure installation. Ensure it is aligned properly with the stove burner drive mechanism, and connect to a single-phase 220V AC power supply. Follow manufacturer guidelines for electrical wiring and safety procedures.

Q: What makes this motor suitable for continuous operation in industrial environments?

A: Engineered with insulation class B, the motor is rated for continuous duty (S1) and features cooling via air flow. Its thermal protection system and high-quality ball bearings are designed to endure extended hours of operation with a service factor of 1.0, making it ideal for demanding commercial kitchens.

Q: Where can this motor be used?

A: This motor is compatible with a wide range of industrial gas stove models. It is most effective in commercial kitchens, canteens, hospitality spaces, and in any industrial setting requiring robust, reliable burner motorization.

Q: What steps are involved in maintaining this motor for a long service life?

A: Routine maintenance includes periodically checking for dust and debris accumulation on the air inlet, ensuring the shaft and bearings are lubricated as needed, and inspecting electrical connections. Its sealed design reduces maintenance needs, but scheduled servicing improves longevity.

Q: When should I consider replacing the motor?

A: Replacement is advised if you notice persistent noise above 60 dB, reduced rotation speed, excessive temperature rise, or visible signs of wear and corrosion. Regular inspection will help identify these issues early.

Q: What are the key benefits of using this induction motor for stove burners?

A: Key advantages include energy efficiency, corrosion resistance, thermal protection, robust cast iron construction, long operational lifespan, and compatibility with various stove models. Its IP44 rating and low noise operation further enhance workplace safety and user comfort.

Q: How does the thermal protection work in this burner motor?

A: The built-in thermal protection mechanism automatically disconnects power if the motor's temperature rise exceeds safe limits (<60K), thereby preventing overheating and extending the motor's operational life.
